Automotive Math and Motor Control Library (AMMCLib)

画像にカーソルを合わせると拡大表示されます。

The Automotive Math and Motor Control Library (AMMCLib) set provides essential building blocks for rapid development of automotive embedded applications with high-performance arithmetic, trigonometric, digital signal processing and math functions. The AMMCLib is available as a production-ready precompiled or source code package.

A significant portion of the AMMCLib supports both sensor-based and sensorless motor control applications; it also assists with fixed-point fractional 16/32-bit and single-precision floating-point arithmetic. All AMMCLib functions come with MATLAB^® and Simulink^® bit-accurate models for model-based design, simulation and code generation supporting Embedded Coder^®.

ソフトウェア詳細

図

図を選択する。:

Auto AMMCLIB General Architecture

Auto AMMCLIB Architecture for KEA

Auto AMMCLIB Architecture for S32Z/E and S32V

Automotive software General Block Diagram

図を取得する PDF

Features

Developed according to SPICE Level 3, ISO/TS 16949:2009, in conjunction with ISO 9001:2008 processes. Also compliant with ISO/IEC 9899:1999
Common interface across all platforms for easy migration and CPU-specific internal optimizations for maximum performance: takes advantage of SIMD extensions: SPE, LSP, Arm^® Neon, Arm DSP for Cortex^®-M
Long-term support of new and old MCUs: new features regularly released for all supported platforms
MATLAB and Simulink models for design, simulation and code generation
Supports NXP S32 Design Studio (S32DS), NXP CodeWarrior^®, Green Hills MULTI, Wind River Diab, IAR for Arm and Cosmic^® compilers (supported compilers may vary based on the device)
AMMCLib comprehensive hierarchy:
- Saturated arithmetic and bitwise functions (MLIB) with basic low-level inline functions
- General trigonometric and controller functions (GFLIB) with a fast trigonometric, look-up table, limitations, hysteresis, logarithm and controller functions
- General motor control functions (GMCLIB) with space vector modulation, transformations and other dedicated motor control functions
- General digital filters functions (GDFLIB) with FIR, IIR and EWMA digital filters
- Advanced motor control functions (AMCLIB) with FOC macroblocks, BEMF observers for sensorless applications, on-the-fly startup and robust PMSM field weakening controller
- Advanced digital filters functions (ADFLIB) with sensor processing and fusion, advanced simulation for calibration, fast Fourier transform (FFT) and general matrix/vector functions available for Arm Cortex-A53 and R52 based MCUs

AMMCLIB Offerings Table

AMMCLib set for:	Free Production Object Code Version	Licensed Production Source Code Version
S32V234	SW32V23-MMCL1D Download	SW32V23-MMCL1C Buy From NXP
S32Z and S32E	Contact NXP for more information about evaluation license for S32Z and S32E	Contact NXP for more information about evaluation license for S32Z and S32E
S32K3	SW32K3-MMCL1D Download	SW32K3-MMCL1C
S32K14x	SW32K14-MMCL1D Download	SW32K14-MMCL1C
S32K11x	SW32K11-MMCL1D Download	SW32K11-MMCL1C Buy From NXP
MPC5775E	SW5775E-MMCL1D Download	SW5775E-MMCL1C
MPC577xC	SW577xC-MMCL1D Download	SW577xC-MMCL1C Buy From NXP
MPC577xK	SW577xK-MMCL1D Download	SW577xK-MMCL1C Buy From NXP
MPC577xM	SW577xM-MMCL1D Download	SW577xM-MMCL1C Buy From NXP
MPC574xC	SW574xC-MMCL1D Download	SW574xC-MMCL1C Buy From NXP
MPC574xG	SW574xG-MMCL1D Download	SW574xG-MMCL1C Buy From NXP
MPC574xP	SW574xP-MMCL1D Download	SW574xP-MMCL1C Buy From NXP
MPC574xR	SW574xR-MMCL1D Download	SW574xR-MMCL1C Buy From NXP
MPC567xF	SW567xF-MMCL1D Download	SW567xF-MMCL1C Buy From NXP
MPC567xK	SW567xK-MMCL1D Download	SW567xK-MMCL1C Buy From NXP
MPC564xL	SW564xL-MMCL1D Download	SW564xL-MMCL1C Buy From NXP
MPC560xB	SW560xB-MMCL1D Download	SW560xB-MMCL1C Buy From NXP
MPC560xP	SW560xP-MMCL1D Download	SW560xP-MMCL1C Buy From NXP
MC9S12ZVM	SWS12Z-MMCL1D Download	SWS12Z-MMCL1C Buy From NXP
KEAx	SWKEA-MMCL1D Download	SWKEA-MMCL1C
