Note: K32W061/41 is preferred for any new Zigbee®, Thread and Bluetooth® LE 5.0 design. No new software releases planned
The FRDM-KW40Z is a low-cost development platform enabled by the Kinetis® W series KW40Z/30Z/20Z (KW40Z) family built on the Arm® Cortex®-M0+ processor featuring an integrated 2.4 GHz transceiver supporting Bluetooth® Smart/Bluetooth® Low Energy v4.1 and/or IEEE® 802.15.4-2011 standards.
The FRDM-KW40Z kit contains two boards, enabling point-to-point out of the box connectivity. Each board can be configured as a FRDM development board or as a FRDM shield. The FRDM-KW40Z hardware is form-factor compatible with the Arduino® Rev3 pin layout, providing a broad range of expansion board options.
The FRDM-KW40Z features a highly-sensitive, optimized 2.4 GHz radio with PCB F-antenna which can be bypassed for connection to test equipment via SMA connection, multiple power supply options, push and capacitive touch buttons, switches, LEDs and integrated sensors.
Supports MKW40Z160VHT4, MKW30Z160VHM4, MKW20Z160VHT4 Kinetis® W MCUs
MKW40Z Arm® Cortex®-M0
Freedom Development boards for Kinetis KW20Z, KW30Z and KW40Z MCUs.
