MCX C15 and MCX C16 Entry-Level, Low-Cost MCUs with Arm® Cortex®-M23 and Advanced Peripherals
- このページでは、試作品の情報を掲載しています。ここに記載されている仕様や情報は、予告なく変更されることがあります。追加情報については、 または営業担当者にお問い合わせください。
The MCX C15 and MCX C16 microcontrollers (MCUs) are low‑cost, entry‑level devices featuring an Arm® Cortex®‑M23 core running at up to 72 MHz, with memory configurations offering up to 64 KB of flash memory and 16 KB of SRAM. These devices bring precision analog and control peripherals into the low‑cost, entry‑level MCU class, making advanced features—such as a 16‑bit analog‑to‑digital converter (ADC), comparator with digital‑to‑analog converter (DAC) and flexible pulse‑width modulation (FlexPWM) for motor control—accessible to cost‑sensitive IoT applications.
Designed as an upgrade path from legacy 8‑bit and 16‑bit MCUs, as well as devices based on Arm Cortex‑M0+ cores, this entry‑level 32‑bit MCU series delivers higher performance and greater scalability without increasing costs. Simple migration paths from widely used LPC800, LPC1100 and Kinetis MCUs—along with pin‑to‑pin compatible options within the newer MCX A Series—enable a seamless transition across the NXP MCU portfolio.
製品詳細
ブロック図
Features
Core Platform
- Arm Cortex-M23, up to 72 MHz
Memory
- Up to 64 KB flash memory, up to 12 KB RAM—8 KB with error correction code (ECC)
Advanced Analog
- 16‑bit successive approximation register (SAR) analog‑to‑digital converter (ADC), up to 18 channels, up to 2.4 MSPS, up to 3 MSPS in 12-bit mode
- High‑speed comparator with internal 8‑bit digital‑to‑analog converter (DAC)
- Operational amplifier (OpAmp) with programmable gain
Motor Control
- 1× FlexPWM module, with three submodules providing six complementary pulse‑width modulation (PWM) outputs
Timers
- Up to 2x 32‑bit standard general‑purpose asynchronous timers/counters
- Low‑power timer
- Frequency measurement timer
- Windowed watchdog timer
- Real‑time clock (RTC) supporting external crystal (XTAL)
Connectivity Interfaces
- 1× Low Power Inter-Integrated Circuit (LPI²C), 1× Low Power Serial Peripheral Interface (LPSPI), 4× universal asynchronous receiver-transmitter (UART)
- Up to 45 general‑purpose input/output (GPIO) pins
Power and Operation
- Operating voltage: 1.71 V to 3.6 V
- Operating temperature: -40 ℃ to 125 ℃
Package Options
- QFP48: 7 x 7 x 1.4 mm, 0.5 mm pitch
- QFN48: 7 x 7 x 0.9 mm, 0.5 mm pitch
- QFN32: 5 x 5 x 0.9 mm, 0.5 mm pitch
- QFN24: available Dec. 2026
- QFN16: available Dec. 2026
