The LS2 family of processors delivers unprecedented performance and integration for the smarter, more capable networks of tomorrow. The eight core LS2088A and the four core LS2048A multicore processors offer Arm^® Cortex^®-A72 cores with the advanced, high-performance datapath and network peripheral interfaces required for networking, telecom/datacom, wireless infrastructure, military and aerospace applications.

The next-generation datapath architecture combined with a powerful software toolkit provides a higher level of hardware abstraction and makes software development quick and simple.

This combination balances ease-of-use with high-performance processing in a Linux^® environment that is familiar to any software programmer. Customers can fully exploit the underlying hardware and easily adapt to network changes for real-time 'soft' control over the network.

Layerscape processors are part of NXP's EdgeVerse™ edge computing platform.

データ・シート

リファレンス・マニュアル

製品詳細

ブロック図

LS2088A Processor Block Diagram

図を取得する PDF

Features

Core Complex

Eight 64-bit Cortex-A72 CPUs
- Up to 2 GHz,
- Clusters of two cores sharing 1 MB L2 cache
1 MB L3 platform cache
Two 64-bit DDR4 SDRAM memory controllers
- ECC and interleaving support,
- Up to 2.1 GT/s

Networking Elements

Wire Rate I/O processor, featuring:
- 8x 10 GbE
- 8x 1 GbE
- L2 switching on the Ethernet interface
- XAUI/XFI/KR and SGMII
- MACSec on up to four 1/10 GbE
2x SATA 3.0
4x PCIe Gen 3 controllers
SR-IOV support, Root Complex

Accelerators and Memory Control

Accelerated I/O processing (AIOP) at up to 20 Gb/s packet processing
20 Gb/s SEC crypto acceleration
10 Gb/s Pattern Matching Engine
20 Gb/s Data Compression Engine
One secondary 32-bit DDR4 memory controller for the accelerated packet processing layer, up to 1.6 GT/s
4 PCIe controllers (Gen3) supporting 1x8, 4x4, 4x2, 4x1 lane configurations

Basic Peripherals and Interconnect

Support for hardware virtualization and partitioning enforcement
Implements trust architecture combined with TrustZone^{^®}
- Service processor (SP) provides pre-boot initialization and secure-boot capabilities
2x USB 3.0 with PHY
Enhanced secure digital host controller
Serial peripheral interface (SPI) controller
Quad Serial peripheral interface (QSPI) controller
Four I2C controllers
Two DUARTs
Integrated flash controller (IFC 2.0) supporting NAND and NOR flash

LS20x4A Family Comparison Table

	LS2088A	LS2048A	L2084A	LS2044A
A-72 Cores	8	4	8	4
L2 Cache (MB)	4	2	4	2
Packet Processing Accelerator	20Gb/s	20Gb/s	No	No
L2 Switch	Yes	Yes	Yes	Yes
