QorIQ® Qonverge BSC9132 Dual-Core Processor and Dual-Core DSP
The BSC9132 is a highly integrated device that targets small cell base station, enterprise VoIP, smart grid control, military/defense and industrial applications. The BSC9132 device combines two e500 cores, built on Power Architecture® technology, and two StarCore® SC3850 cores with MAPLE-B2P baseband acceleration processing elements to address the need for a high-performance, low-cost, integrated solution that handles a broad range of specialist DSP functions with complimentary high-performance general purpose processing.
For small cell applications, the BSC9132 supports multimode operation with 20 MHz LTE TDD or FDD, and WCDMA 5 MHz.
製品詳細
Features
- Power Architecture subsystem including two e500 processors with 512-Kbyte shared L2 cache
- Two StarCore® SC3850 DSP subsystems, each with a 512-Kbyte private L2 cache
- The MAPLE-B2P multi-accelerator platform engine supports functions that enable LTE-FDD/TDD, WiMAX and WCDMA/HSPA+ wireless standards, as well as common DSP function acceleration including FFT, DFT and Turbo Viterbi coding
- Two DDR3/3L memory interfaces with 32-bit data width (40 bits including ECC), up to 1333 MHz data rate
- Integrated security acceleration (SEC)
- Trust architecture secure boot
- Two RF interfaces supporting JESD207 (ADI)
- Support of MaxPhy interface (Maxim)
- Two triple-speed Gigabit-Ethernet controllers featuring network acceleration including IEEE 1588™ v2 hardware support for two SGMII ports
- USB 2.0 host and device controller
- Two DUART, Two SPI, and two I2C controllers
- Four-lane SerDes PHY that multiplexes the following:
- Two Common Public Radio Interface (CPRI) controller lanes
- USIM interface
