AUTOSAR 4.3 Drivers for SJA1105P/Q/R/S
SJA1105PQRS-AUTOSAR-SW アラートの受信
The SJA1105P/Q/R/S AUTOSAR driver is production-grade software according to AUTOSAR 4.3 specifications. The driver supports all four SJA1105P/Q/R/S Ethernet switch variants using a single codebase. It has been developed on top of NXP MCAL but it can operate with any third party AUTOSAR MCALs and external processor.
ソフトウェア詳細
Features
- ASIL-D qualified for integration in safety-critical applications like Gateway/ADAS/Powertrain/Chassis.
- Timestamping/gPTP* support for cascaded switches.
- Time-Aware Shaper (TAS) support for scheduled traffic based on 802.1Qbv.
- Per-Stream Filtering and Policing (PSFP) for increased security.
- Additional security-relevant configuration options for dynamic learning, double tagging, asymmetric VLANs, broadcast policers etc.
- Advanced ARL table configuration based on TCAM.
- Out of the box example application using SJA1105SMBEVM: Gateway Prototyping Platform.
対応製品
- MPC574xB-C-G: Ultra-Reliable MPC574xB/C/G MCUs for Automotive and Industrial Control and Gateway
- SJA1105PQRS: SJA1105PEL/QEL/REL/SEL Series Ethernet Switches
設計・リソース
関連ソフトウェア
1 ソフトウェア・ファイル
-
BSPとデバイスドライバ
AUTOSAR 4.2.x (Classic Platform) Software
