NFC Everywhere
Controller, frontend and connected-tag solutions for the next generation of NFC applications.
お客様の素早い設計とより早い製品化を実現する、技術情報と専門知識をご紹介します。
NFC readers are the active components in NFC transactions. They can read and write cards and tags, interact with NFC phones and enable a communication from device to device. We have the broadest portfolio of high-performance NFC readers, fully supporting the MIFARE® ICs.
Depending on your system architecture, choose from one of these three reader types:
Part Number | NFC Modes | Protocols* | Output Power | LPCD* performance | Contact Reader ISO7816 | RF transmitter supply voltage | Temp range | Integrated MCU |
---|---|---|---|---|---|---|---|---|
PN7462AU Programmable NFC microcontroller |
Full NFC | A, B, F, V, I | 1.3 W | ++ | 3 to 5.5 V | -40 to +85°C | Cortex-M0 160 kB | |
PN7362AU Programmable NFC microcontroller |
Full NFC | A, B, F, V, I | 1.3 W | ++ | - | 3 to 5.5 V | -40 to +85°C | Cortex-M0 160 kB |
PN7360AU Programmable NFC microcontroller |
Full NFC | A, B, F, V, I | 1.3 W | ++ | - | 3 to 5.5 V | -40 to +85°C | Cortex-M0 80 kB |
PN7150 NFC controller with integrated FW* |
Full NFC | A, B, F, V | 0.9 W | ++ | - | 2.7 to 4.75 V | -30 to +85°C | Cortex-M0 fixed FW |
PN7120 NFC controller with integrated FW* |
Full NFC | A, B, F, V | 0.5 W | ++ | - | 3.1 V | -30 to +85°C | Cortex-M0 fixed FW |
PN5180 High-perf full NFC frontend |
Full NFC | A, B, F, V, I | 1.3 W | ++ | - | 2.7 to 5.5 V | -30 to +85°C | - |
CLRC663 plus High-perf multi-protocol reader frontend |
Reader/Writer | A, B, F, V, I | 1.9 W | +++ | - | 2.5 to 5.5 V | -40 to +105°C | - |
MFRC630 High-perf reader frontend for MIFARE® and NTAG® products |
Reader/Writer | A | 1.3 W | + | - | 3 to 5.5 V | -25 to +85°C | - |
SLRC610 High-perf reader frontend for ICODE® products |
Reader/Writer | V,I | 1.3 W | + | - | 3 to 5.5 V | -25 to +85°C | - |
*Protocols: A: ISO/IEC 14443A; B: ISO/IEC 14443B; F: FeliCa; V: ISO/IEC 15693 (Vicinity); I: ISO/IEC 18000-3M3 (ICODE ILT)
LPCD: Low Power Card Detection
FW: Firmware
