MIFARE DUOX®: High security contactless smartcard IC

画像にカーソルを合わせると拡大表示されます。

As the first contactless smartcard IC in its class to combine asymmetric and symmetric cryptography in a single chip, MIFARE DUOX simplifies key management and key distribution. By adding certificate management capabilities, delivering enhanced features and security with CC EAL6+ certification, MIFARE DUOX enables high performing, highly secure and cost-effective NFC system solutions for access management, secure car access, EV-charging applications, and more.

データ・シート

アプリケーション・ノート

製品詳細

ブロック図

MIFARE DUOX

図を取得する PDF

Features

Certification and Compliancy

ISO/IEC 14443 A levels 1-4
ISO/IEC 7816-4
ISO/SAE 21434 automotive cybersecurity compliant
Common Criteria EAL 6+ certified hardware and software
NFC Forum Tag Type 4
MISRA-C coding standard compliant

RF Interface and ISO/IEC 14443 Type A

Contactless interface compliant with ISO/IEC 14443-2/3 A
Fast data transfer with baud rate of 106 kbit/s, 212 kbit/s, 424 kbit/s, 848 kbit/s and support of VHBR
13.56 MHz operating frequency
Low Hmin enabling operating distance up to 100 mm (depending on power provided by the PCD and antenna geometry)
Configurable FSCI to support up to 256-bytes frame size

Nonvolatile Memory

User memory size of 2 kB, 4 kB, 8 kB and 16 kB
Data retention of 25 years
Write endurance up to 1,000,000 cycles
True multiapplication support with secure separation between applications
Flexible file system with data management structured into applications and files
File access rights management via assignment of access conditions per file
Interapplication file and data sharing
Delegated Application Management (DAM) functionality for easy postissuance application installation of third parties

Security and Privacy

Symmetric cryptographic algorithms: AES-128, AES-256
Symmetric AES-based mutual authentication establishing a secure channel
Future proof for PQC era (Post-Quantum-Crypto) with AES-256
Asymmetric cryptographic algorithms and key management: ECC with NIST P-256 and brainpoolP256r1 curves
Asymmetric ECC-based mutual authentication, reader-unilateral authentication and card-unilateral authentication establishing a secure channel
ECC signature generation via ECDSA and SHA-256
Simplified key management and key distribution via private/public key management and PKI concept
Key management on card level: 2 preinjected asymmetric keypairs and certificates; 11 reserved slots for symmetric keys
Key management on application level: up to 5 certificates per application; up to 14 symmetric keys per application (in up to 16 keysets)
Self-securing file system
Hardware exception sensors

Extended Features

Proximity Checks to detect relay attacks based on round-trip time measurement
Transaction Signature and Transaction MAC generating a secure proof of executed transactions
Transaction Timer to prevent Man-in-the-Middle attacks
Secure Dynamic Messaging to ensure security and integrity protected NDEF data reading
Dynamic Originality Checks based on ECC, verifying the genuineness of the IC via card-unilateral ECC-based authentication
NXP offered Trust Provisioning service to preinject data and key material securely by your trusted semiconductor manufacturer

EV-Charging Functionality (on "MIFARE DUOX EV" part types)

Availability of dedicated part types for EV-Charging with "MIFARE DUOX EV"
Support of EV-Charging specific command set as defined in VDE-AR-E 2532-100
Preinstalled EV-Charging application and file structure as defined in VDE-AR-E 2532-100
Preinjected key material and certificates, issued by the NXP EV-Charging CA, as defined in VDE-AR-E 2532-100
Ready-made solution for EV-Charging and interoperability between multiple CPOs and EMSPs

Additional Aspects

Extended operating temperature range for industrial and automotive applications: -40 °C up to +105 °C on silicon level
Unique 7 bytes serial number (UID) for each IC, as per ISO/IEC 14443-3 requirements
Optional configurable 4 byte random ID (RID)
Compatibility to MIFARE DESFire application and file system layout and EV2 secure messaging
Delivery forms as 75 µm sawn and bumped wafer and MOA8 contactless smart card module
Input capacitance options with 17 pF and 70 pF for different form factor designs (smartcards, wristbands, key fobs, tokens, stickers, and so on)

購入/パラメータ

‌ ‌ ‌	‌ ‌	‌ ‌	‌ ‌	‌ ‌	‌ ‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌
‌ ‌ ‌	‌	‌	‌	‌	‌

ドキュメント

クイック・リファレンスドキュメンテーションの種類.

4 ドキュメント

コンパクトリスト

MIFARE DUOX Quick Start Guide[AN14217]

PDFNov 14, 2024改訂 1.0

MIFARE Trademark Usage Guidelines[MFTMKBRNDG]

PDFMar 10, 2025改訂 5.2

MIFARE DUOX Contactless Smartcard IC[MF3EHx3_SDS]

PDFNov 12, 2024改訂 1.0

MIFARE DUOX Factsheet[MIFAREDUOXFSA4]

PDFNov 19, 2024改訂 1.0

設計・リソース

デザイン・ファイル

完全な内訳を受け取ります。 製品の設置面積などについては、 eCad ファイル.

ハードウェア

クイック・リファレンスボードタイプ.

1 ハードウェア提供

完全なソリューション
PN7642ベースのPegodaスマートカード・リーダー

CLRD730

ソフトウェア

クイック・リファレンスソフトウェア・タイプ.

3 ソフトウェア・ファイル

スニペット、ブート・コード、ヘッダ、モニタなど
RFIDDiscover
ライブラリ
NFC Reader Library: Software Support for NFC Frontend Solutions

ダウンロード・オプション
ライブラリ
TapLinx Software Development Kit (SDK)

ダウンロード・オプション

注: より快適にご利用いただくために、ソフトウェアのダウンロードはデスクトップで行うことを推奨します。

トレーニング

1 トレーニング

オンデマンドウェビナー
Introducing MIFARE DUOX: Simplifying Security in Smart City Applications

Discover how MIFARE DUOX's flexibility and enhanced security with asymmetric cryptography make it a versatile, future-proof smartcard IC for EV charging, car access, and access management.

1 hrEnglish レベル: 初級編
