NTAG® 213 TagTamper: NFC T2T Compliant IC with TagTamper Feature
NT2H1311TTDUF アラートの受信
Please check the new online NFC Antenna Tool for tag and reader devices.
NTAG 213 TagTamper offers extended features compared to the NTAG 213 providing additional benefits for smart packaging and brand protection. NTAG 213 TagTamper the new TagTamper functionality, which is detecting the status of a TagTamper wire during the startup. In case of an open detection wire, the NTAG 213 TagTamper permanently stores this event. Information status of the TagTamper wire can be mirrored in ASCII code into the user memory, which contains the NDEF message or can be read with a dedicated command.
Further on the NTAG 213 TagTamper offers the improved originality signature, which can be programmed and locked during the tag initialization.
The NTAG 213 TagTamper is fully compliant to NFC Forum Type 2 Tag and ISO/IEC14443 Type A specifications.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by NXP® Semiconductors is under license.
製品詳細
Features
- Contactless transmission of data and supply energy
- Operating frequency of 13.56 MHz
- Data transfer of 106 kbit/s
- Data integrity of 16-bit CRC, parity, bit coding, bit counting
- Operating distance up to 100 mm (depending on various parameters as, e.g., field strength and antenna geometry)
- 7-byte serial number (cascade level 2 according to ISO/IEC 14443-3)
- UID ASCII mirror for automatic serialization of NDEF messages
- Automatic NFC counter triggered at a reading command
- NFC counter ASCII mirror for automatic adding the NFC counter value to the NDEF message
- Tag Tamper feature detecting if the TagTamper wire is open after startup
- Tag Tamper message ASCII mirror copying the customized Tag Tamper message into the NDEF message if there is a detected tamper event
- ECC-based originality signature, offering the possibility for customizing and permanently locking
- Fast read command
- True anti-collision
- 50 pF input capacitance
- 184 bytes organized in 46 pages with 4 bytes per page
- 144 bytes freely available user Read/Write area (36 pages)
- 4 bytes initialized capability container with one-time programmable access bits
- Field programmable read-only locking function per page for the first 16 pages
- Field programmable read-only locking function above the first 16 pages per double page
- Configurable password protection with an optional limit of unsuccessful attempts
- Anti-tearing support for capability container (CC) and lock bits
- Preprogrammed ECC-based originality signature, offering the possibility for customizing and permanently locking
- TagTamper message
- Data retention time of 10 years
- Write endurance 100.000 cycles
Target Applications
- Product authentication
- Smart packaging
- Smart advertisement
- Goods and device authentication
- Voucher and coupons
- Bluetooth® or Wi-Fi pairing
- Electronic shelf labels
