12-Channel Power Management Integrated Circuit (PMIC) for High-Performance Consumer Applications

動画の上をクリックすると再生されます。

ブロック図

PF8121, 12-channel PMIC

PF8121, 12-channel PMIC Block Diagram

Features

System Features

  • Up to seven high-efficiency buck converters
  • Four linear regulators with load switch options
  • RTC supply and coin cell charger
  • Watchdog timer/monitor
  • Voltage and system monitoring circuits
  • One-time programmable device configuration
  • 3.4 MHz I2C communication interface
  • 56-pin 8 x 8 QFN package
  • i.MX 8M Mini MCU supported
  • Output current 10 A
  • Fast PMIC startup
  • Advanced state machine for seamless processor interface
  • High-speed I2C interface and input control (3.4 MHz)
  • PGOOD monitor
  • User programmable standby and off modes
  • Programmable soft start sequence and power down sequence
  • Programmable regulator configuration
  • 24 channel analog multiplexer for smart system monitoring/diagnostic

Programmability

  • Supplies, sequencing, and specific functions can be programmed by One Time programmable (OTP) memory
  • Standard Predefined OTP supporting popular MCU can be found in data sheet under “ordering information” chapter
  • During development phase, Customized OTP part can be programmed using the KITPF8200FRDMPGM: board
  • Custom OTP can be provided for production. Please contact your NXP sales channel (NXP or your distributor)
  • Custom OTP form can be downloaded PF8121 Custom OTP Request Form or using the OTP tool integrated in the NXP GUI Software Tool

Product Longevity Program

  • This product is included in the NXP Product Longevity program ensuring a stable supply of products for your embedded designs. MC32PF8121 is included in the 10-year program
