CodeWarrior® Development Studio for ColdFire® Architectures (Classic IDE) v7.2

CW-COLDFIRE

画像にカーソルを合わせると拡大表示されます。

CodeWarrior® Development Studio for ColdFire® Architectures v7.2 is a single, integrated tool suite designed to get you on the design fast track with ColdFire V2, V3, V4 and V4e members of the NXP® Controller Continuum. By combining state-of-the-art debugging technology with the simplicity of a robust development environment, CodeWarrior Development Studio takes source-level debugging and embedded application development to a new level.

ソフトウェア詳細

セクションを選択:

Features

  • Classic IDE
  • Unlimited assembler
  • Unlimited C/C++ Compiler and Debugger (restrictions based on suite)
  • Integrated flash programmer
  • Flash tool kit to create flash programming algorithms for external memory devices
  • Device Initialization tool
  • Processor Expert® with Basic, Software and Advanced Components (restrictions based on suite)
  • Processor Expert Component Wizard (restrictions based on suite)
  • RTOS awareness (restrictions based on suite)
  • Profile Analysis (restrictions based on suite)
  • Support for new ColdFire® derivatives
  • New ColdFire compiler with Embedded Warrior Libraries (EWL), which focus on reducing the memory footprint taken by I/O operations and simplifying memory allocation
  • Support for the new NXP® Open Source BDM connection on the M52259DEMO board
  • Compatible with MQX™ RTOS 3.6
  • Online help and documentation
  • Includes 12-month technical support
  • Free 30-day evaluation license available

対応製品

システム要件



Specifications

  • Build tools output formats:
    • ELF/DWARF 2.0
    • NXP S Record
    • Intel® hex
    • binary
  • Host target interfaces:
    • CodeWarrior USB TAP
    • CodeWarrior Ethernet TAP
    • Cyclone Max
    • USB BDM Multilink
    • Parallel BDM Multilink
    • Lightning (P&E Microsystems)
    • BDI1000 and BDI2000 (Abatron)
    • Open Source BDM (S08JM60 based)
  • Board support:
    • ColdFire V2:
      • M5208EVBE
      • M5235EVB
      • M5253EVBE
      • M52230DEMO
    • ColdFire V3:
      • 5329EVBE
    • ColdFire V4e:
      • M5475EVBE
      • M5485EVBE

ダウンロード

フィルタ

1-5 の 6 ダウンロード

  • BSPとデバイスドライバ

    2008 Linux BSP for Freescale M52277EVB (12-Dec-2008)

    ISO改訂 2.0Dec 12, 2008 00:00:00422788 KBCWF-M52277EVB
    ダウンロード
  • BSPとデバイスドライバ

    2008 Linux BSP for Freescale M5329EVB Update (07-Jul-2008)

    ISO改訂 4Dec 15, 2008 00:00:00385846 KBCWF-MCF5329EVB
    ダウンロード
  • BSPとデバイスドライバ

    Linux BSP for Freescale MCF5373EVB

    ISO改訂 1Nov 9, 2007 00:00:00348202 KBCWF-M5373EVB
    ダウンロード
  • BSPとデバイスドライバ

    2008 Linux BSP for MCF5484LITE, MCF5475/85EVB (08-Aug-2008)

    ISO改訂 3Aug 11, 2008 00:00:00423852 KBCWF-MCF547X-548X-2-6-KL
    ダウンロード
  • BSPとデバイスドライバ

    Linux BSP for M54455EVB Update

    TGZ改訂 v1.1Aug 8, 2008 00:00:0016 KBCWF-MCF54455EVB-update
    ダウンロード
全て表示

注: より快適にご利用いただくために、ソフトウェアのダウンロードはデスクトップで行うことを推奨します。

ドキュメンテーション

クイック・リファレンス ドキュメンテーションの種類.

フィルタ

1-5 の 28 ドキュメント

全て表示

サポート

お困りのことは何ですか？?

  • Narrow your search
検索

ライセンスと登録サポート

ハウツー・ビデオ（ライセンス）

    USB Dongle Drivers

    These downloads are applicable for using a USB dongle to license your NXP product. You should receive documentation within your USB dongle kit that has detailed instructions for getting your product up and running with a license tied to the dongle. These downloads along with the most recent Dongle QuickStart Guide are listed below for your convenience.

    License Manager Installers

    These downloads contain the necessary software to install the FLEXlm license manager.  The license manager software should be installed on the license server machine which will facilitate floating licenses for your NXP product.

    Please locate below the appropriate download for your license server machine.  If you are not sure, you should consult with your license server administrator.

    Below is a table that outlines which Operating System versions we officially support and test with our license manager.
    NOTE: Any installation or use outside of this scope will not be officially supported.


    Installer Versions Supported
     Windows  Win2003, Win2008, Win7, Win 8, Win 10
     Windows Server  2019, 1903, 1909, 20H2
     Linux   Red Hat EP v5.x, Red Hat EP v6.x, SUSE 11 Ubuntu 12.04
