400 MHz to 2700 MHz 1 W High-Efficiency Silicon Amplifier

BGA6130

The MMIC is a one-stage amplifier, offered in a low-cost leadless surface-mount package. At 3.6 V it delivers 29.5 dBm output power at 3 dB gain compression with efficiency higher than 55 %. Its power saving features include simple quiescent current adjustment, which allows class-AB operation and logic-level shutdown control to reduce the supply current to 4 μA.

製品詳細

セクションを選択:

Features

  • 400 MHz to 2700 MHz frequency operating range
  • Integrated active biasing
  • External matching allows broad application optimization of the electrical performance
  • Efficiencies higher than 55 %
  • 3.6 V single supply operation
  • Power-down
  • Excellent robustness:
    • All pins ESD protected (HBM 6 kV; CDM 2 kV)
    • Withstands mismatch of VSWR 50 : 1 through all phases
    • Withstands electrical over-stress peaks of 4.5 V on the supply voltage

Target Applications

  • Broadband CPE / MoCA
  • WLAN / ISM / RFID
  • Wireless Sensor Networks (WSN)
  • Industrial applications
  • Satellite Controller Antenna TV (SMATV)
