Gauge Compensated Pressure Sensor (0 to 50 kPa)
As of February 2, 2026, NXP MEMS sensor products have been transitioned to STMicroelectronics. For more information, contact STMicroelectronics.
The MPXx2051 pressure sensor delivers a silicon piezoresistive device with a highly accurate and linear voltage output, directly proportional to the applied pressure.
- Targets medical and industrial applications such as pump/motor controllers, robotics, level indicators, and non-invasive blood pressure measurement
- Provides a single, monolithic silicon diaphragm with the strain gauge
- Includes a thin-film resistor network integrated on-chip
- Delivers a laser-trimmed chip for precise span, offset calibration and temperature compensation
製品詳細
Features
Key Features
- Temperature compensated over 0 °C to +85 °C
- Ratiometric to supply voltage
- Available in easy-to-use tape-in-reel
- Gauge ported
