Differential and Gauge Compensated Pressure Sensor (0 to 50 kPa)
As of February 2, 2026, NXP MEMS sensor products have been transitioned to STMicroelectronics. For more information, contact STMicroelectronics.
The MPX2053/MPXV2053G/MPXM2053 device series offer silicon piezoresistive pressure sensors with highly accurate and linear voltage output directly proportional to the applied pressure.
- Supports applications such as pump/motor control, robotics, level detectors, pressure switching, medical diagnostics, and blood pressure measurement
- Provides a single monolithic silicon diaphragm with the strain gauge and a thin-film resistor network integrated on-chip
- Enables precise span and offset calibration and temperature compensation
製品詳細
Features
Key Features
- Temperature compensated over 0 °C to +85 °C
- Ratiometric to supply voltage
- Available in rails or tape-in-reel shipping options
- Available in differential and gauge configurations
- Gauge-ported and non-ported options
