1 GHz Wideband Low-Noise Amplifier with Bypass
The BGU7042 MMIC is a 3.3 V wideband amplifier with bypass mode. It is designed specifically for high linearity, low-noise applications over a frequency range of 40 MHz to 1 GHz. It is especially suited to Set-Top Box applications. The LNA is housed in a 6-pin SOT363 plastic SMD package.
SOT363
製品詳細
Features
- 75 Ω input and output impedance
- Bypass mode current consumption < 5 mA
- ESD protection > 2 kV Human Body Model (HBM) on all pins
- Flat gain between 40 MHz and 1 GHz
- High linearity with an IP3O of 29 dBm
- Internally biased
- Noise figure of 4 dB
- Power-down during bypass mode
- Programmable between Gp = 10 dB and bypass
- Voltage supply of 3.3 V
Target Applications
- Home networking and in-house signal distribution
- Personal and Digital Video Recorders (PVR and DVR)
- Silicon and “Can” tuners
- Terrestrial and cable Set-Top Boxes (STB)
